⚙️ Technical Information

Model: SL004
Brand: Suitch On
Material: Zinc Alloy
Finish Options: Matte Black / Silver / Rose Gold
Lock Type: Smart Handle Lock (Mortise Type)

🔐 Unlocking Methods

1. Fingerprint Access – High-speed capacitive sensor (<0.5s recognition)
2. RFID Card – Smart keyless access using 13.56 MHz RFID technology
3. Passcode Entry – Supports 6–12 digit PINs with anti-peep function
4. Mechanical Key – Emergency backup access
5. Mobile App (Bluetooth) – Unlock and manage users from the Suitch App

📲 App Features

• Bluetooth unlock & management
• Add or delete users easily
• Real-time access records
• Temporary PIN or eKey sharing
• Low battery notification
• Optional remote unlock (via Wi-Fi gateway)

🔋 Power & Battery

• Power Source: 4 × AA Alkaline Batteries (DC 6V)
• Battery Life: 10–12 months (approx. 10,000 operations)
• Low Battery Warning: LED + App notification
• Emergency Power Supply: Type-C / Micro USB port

🧰 Specifications

• Fingerprint Capacity: Up to 200 users
• Passcode Capacity: Up to 50 sets
• RFID Card Capacity: Up to 100 cards
• Door Thickness Supported: 35mm – 65mm
• Working Temperature: -20°C to 60°C
• Working Humidity: 10% – 90% RH
• Door Direction: Left & Right reversible
• Installation: Suitable for wooden & metal doors

🔒 Security Features

• Auto-locking after door closure
• Anti-peep password entry
• Intrusion and tamper alarm
• Wrong entry lockout protection
• Mechanical key override for emergencies

📦 Package Includes

• 1 × Smart Door Lock Set (SL004)
• 2 × RFID Cards
• 2 × Mechanical Keys
• 1 × Installation Kit & Screws
• 1 × User Manual

🛡️ Warranty

• 1 Year Manufacturer Warranty (for manufacturing defects only)
